TH800 horizontal machining center
Main performance characteristics:
TH800 horizontal machining center can be used in aerospace, automobile, precision machining of internal combustion engines, household appliances, general machinery parts, suitable for working surface milling, drilling, boring, reaming, tapping, two dimensional, three-dimensional surface and other processes, has good performance in a single setup box holes and plane processing U-turn boring, especially suitable for box hole, the machine is equipped with an automatic lubrication system, cooling system, fully enclosedverticalshield.
Base of machine tool base, column, main shaft box, working table and so on are all used high strength lost foam casting molding technology, the internal microstructure is stable, to ensure the high stability of the foundation. After the dynamic analysis and finite element analysis of the machine tool, the structure of the casting is more reasonable, and the proper collocation of the reinforcement bars ensures the high rigidity of the foundation. The wide solid machine tool base, the widening and lengthening of the saddle, the load of the full support of the design, structure in line with the advanced design concept of materials mechanics, can ensure the processing of heavy load capacity.
Main structure
Two structures of the machine tool are fixed with single column, and the working table moves structure. A movable column, a fixed table, composed of bed, column, table, base, head, spindle, wire rod, lubrication system, cooling system, CNC operation panel and electronic control system components.
Main configuration
1 control system: FANUC CNC control system.
2 spindle motor: FANUC servo spindle motor.
3.X, Y, Z, B axis drive motor: Japan FANUC
4.X, Y, Z, B axis servo drive: Japan FANUC (Z axis with brake)
5 spindle: Taiwan Chun lung 6000rpm spindle.
6 wire rod: Taiwan law court precision grade ball screw, C3 level.
The 7 line rail rail line in Taiwan: Silver roller
8 Changzhou Ding booster cylinder.
9 Taiwan sirgel disc knife library
10 Japanese NSK bearings, P4 class.
11 electric cabinet heat exchange constant temperature system.
12 hand held electronic pulse.
13 coupling
14, machine
15 double oil pump automatic lubricating and lubricating alarm device.
16 optional for domestic or Taiwan rotary table
Main parameters:
Model unit TH800
Table size mm 800 * 800
Table division 1 degrees
Maximum load bearing 1200kg Kg
Table T type slot 7/22/100
X/Y/Z axis stroke 1100*1000*900 mm
Spindle center line to the working table distance 150-1100 mm
Spindle speed 4000/6000 rpm
Spindle taper BT50
X, Y, Z axis rapid displacement 15/15/12 m/min
Cutting feed 1-6000 mm
Minimum input unit mm 0.001
Spindle servo motor Kw 22
Y Z X to servo motor 18/28/28 N.m
B servo motor N.m 11
Positioning accuracy 0.005 mm
Repeat precision 0.003 mm
Net weight Kg 13000
Main performance:
1 keyboard control: simple, convenient, easy to learn the split keyboard operation, users can quickly and flexibly grasp the use of equipment, independent of the stronger.
2 intelligent processing cross-border protection function: to prevent the mechanical collision phenomenon caused by the processing rate over the design layout.
3, vacuum adsorption device: cleaning system in the process of sucking sawdust and broken Tim, keep the table clean on equipment maintenance; adsorption system to replace the previous mechanical plate fixed to improve the processing time for handling outside the plate.
4 intelligent processing speed control: can control the processing speed, and truly improve the processing efficiency, director of tool life, improve the rate of finished products.
5 advanced file preprocessing function, to help users to correct the error in the processing file, and can be well compatible with domestic and foreign processing code generation of a variety of software.
6 advanced 3D curve prediction algorithm, the line is smooth, to ensure the running speed and accuracy of the curve.
7 based on the platform of Embedded CNC system, unlimited upgrade function. The anti interference design of hardware and software synchronization to ensure the reliable operation of the system time.
8 has the breakpoint, the power cut continues to carve the function, has the return to the origin automatic error correction function, the effective guarantee in the long time work the processing precision.
The machine adopts 9 steel seamless welded, strong steel, no deformation; Japan FANUC servo motor, the torque is large and has a perfect security system.
Installation conditions
A, temperature
Operating temperature: room temperature 20 20
Storage handling: -30 C ~ 50 C
B, humidity
The following 75%: continuous (without dew)
Short time: 95% (no dew)
C, installation site conditions
1 not affected by external vibration.
2 unaffected by corrosive gases.
3 avoid direct sunlight.
4 to avoid direct contact with the outside air, gas and the temperature of cold and hot air.
5 avoid the heating and other heat source near the machine tool.
6 to reduce dust (to avoid casting, welding, sheet metal workshop, etc.).
7 to avoid leakage, water immersion.
8 avoid electrical noise.
D and power tools: 3 AC380V 10% 50HZ 1HZ ~ 10%.
